MAG CORELIQUID 240R V2 WHITE

MODEL NAME
Front I/O Ports
Drive Bays
VGA Card Support
CPU Cooler Support
Power Supply
Model Name
WEIGHT (CARD)
Number of Fans
Fan Dimensions
Radiator Compatibility
Fan Speed
Fan Power Consumption
Fan Rated Current
Fan Life Expectancy
Fan Bearing
Fan Air Flow
Fan Lighting
PWM Mode
Fan Cable Length (5V ARGB / PWM cable)
Radiator Dimensions
Block Dimensions
Pump Life Expectancy
Pump Noise Level
Pump Speed
Dimensions
Pump Power Consumption
Bearing Type
Rated Speed
Air Flow
Static Air Pressure
Connector
Life Expectancy
Intel Socket
PRODUCT DIMENSIONS (MM)
AMD Socket
WEIGHT (PRODUCT / PACKAGE)
Accessories
Cold Plate Material
Radiator Size

MODEL NAME

MPG GUNGNIR 100

Front I/O Ports

2 x USB 3.0 + HD Audio / Mic

Drive Bays

2 x 3.5" (compatible with 2.5" ) + 4 x 2.5"

VGA Card Support

Max 400mm / 15.75 inch

CPU Cooler Support

Max 170mm / 6.69 inch

Power Supply

Standard ATX

Model Name

TORX FAN 12CM

WEIGHT (CARD)

169g

Number of Fans

Fan Dimensions

120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches

Radiator Compatibility

120 / 140 / 240 mm

Fan Speed

500 ~ 2000 RPM

Fan Power Consumption

1.8 W

Fan Rated Current

0.15 A

Fan Life Expectancy

70,000 hours

Fan Bearing

Two Ball Bearing

Fan Air Flow

21.63 ~ 78.73 CFM

Fan Lighting

ARGB

PWM Mode

YES

Fan Cable Length (5V ARGB / PWM cable)

550 / 350mm; 21.65 / 13.78 inches

Radiator Dimensions

274 x 120 x 27mm / 10.79 x 4.7 x 1.06 inches

Block Dimensions

80.57x 66.82 x 48.58mm

Pump Life Expectancy

100,000 hours

Pump Noise Level

18 dBA

Pump Speed

4200 RPM +-10%

Dimensions

120mm x 120mm x 25.6mm

Pump Power Consumption

4.08W

Bearing Type

Hydro-Dynamic Bearing

Rated Speed

500 - 1800 ±15% RPM

Air Flow

19.79 - 71.27 CFM

Static Air Pressure

0.16 - 2.09 mm-H20

Connector

4-Pin PWM/DC

Life Expectancy

MTTF 150,000 Hours (25℃)

Intel Socket

LGA 1150/1151/1155/1156/1200/1700
LGA 1366/2011/2011-3/2066

PRODUCT DIMENSIONS (MM)

510(D) x 227(W) x 525(H) mm
20.08(D) x 8.94(W) x 20.67(H) inch

AMD Socket

AM5/AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2

WEIGHT (PRODUCT / PACKAGE)

9.3 KG

Accessories

1 to 2 Fan PWM cable x 1
PSU Molex 4-Pin to 4-Pin(2 Pin Wired) Fan cable x 1

Cold Plate Material

Copper

Radiator Size

240mm
